10 bp DNA Ladder

OverviewTechnical/SpecsLiterature/SupportOrdering Information

10 bp DNA Ladder is designed for determining the size of double stranded DNA from 10 to 100 bp

10 bp DNA Ladder is designed for determining the size of double stranded DNA from 10 to 100 bp. The ladder consists of 10 double stranded DNA fragments ranging in size from 10 to 100 bp in 10 bp increments, The DNA marker fragments at 40bp bands are two times brighter for easy identification.

Note

The DNA ladder can be applied directly onto an agarose gel. There is no need to heat before loading.
Repeated freezing and thawing should be avoided.

Features and Benefits

Complete and ready to load: Convenient

Easy-to-Identify reference bands: Easy-to-read results

Competitive pricing: Great value for your research dollar

Specifications

Concentration	522 ng/uL
Recommended loading	1.5 ~ 2.0 uL/ 5mm lane width
Size Range (bp)	10 ~ 100
Number of Bands	10
Supplied in	10 mM Tris-HCl (pH 8.0), 1mM EDTA, 5% Ficoll, 0.012% Bromophenol Blue, 0.01%Xylene Cyanol, 0.08% Orange G
Storage	-20°C

Application

Figure 1. Bioneer’s 10 bp DNA ladder shows distinguishable and high resolution band than company P 10bp ladder (Gel running time: 60 min).
Lane A: bioneer 10bp DNA ladder (cat No. D-1010)
Lane B: Company P 10bp ladder

Manual

• 10 bp DNA Ladder

MSDS

• 10 bp DNA Ladder

Brochure

• DNA Ladders and Makers

Quality Assurance

Bioneer is the holder of Quality Management System Certificates for the following standards.

• ISO 9001:2008 - certificate

• EN ISO 13485:2003 / AC:2009 - certificate
